CA4-31E is a 4-pole front mounted auxiliary contact block equipped with screw terminals, designed for ABB AF/AFC series contactors. It provides 3 N.O. and 1 N.C. instantaneous contacts for standard industrial control environments.
| Parameter | Value |
|---|---|
| Product Type | Auxiliary Contact Block |
| Model | CA4-31E |
| Contact Configuration | 3 NO + 1 NC |
| Number of Poles | 4 |
| Mounting Type | Front mounting |
| Terminal Type | Screw Terminals |
| Rated Insulation Voltage (Ui) | 690 V (IEC), 600 V (UL/CSA) |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Voltage | 690 V (Auxiliary Circuit) |
| Conventional Thermal Current (Ith) | 16 A |
| Contact Current Rating | 6 A |
| Rated Operational Current AC-15 (Ie) | 4 A @ 220-240V; 6 A @ 24-127V; 3 A @ 400-440V; 2 A @ 500-690V |
| Rated Operational Current DC-13 (Ie) | 6 A @ 24V; 2.8 A @ 48V; 1 A @ 72V; 0.55 A @ 125V; 0.27 A @ 250V |
| Rated Frequency | 50 / 60 Hz |
| Max Mechanical Switching Frequency | 3600 cycles/hour |
| Max Electrical Switching Frequency | 1200 cycles/hour (AC-15); 900 cycles/hour (DC-13) |
| Rated Short-time Withstand Current (Icw) | 140 A for 0.1s; 100 A for 1s |
| Mechanical Durability | 10 million cycles |
| Degree of Protection | IP20 (Auxiliary Terminals) |
| Operating Temperature Range | -40°C to +70°C |
| Tightening Torque | 1.2 N·m |
| Wire Stripping Length | 10 mm |
| Pilot Duty UL/CSA | A600, Q600 |
| Standards | IEC/EN 60947-5-1, UL 60947-5-1, CSA C22.2 No.60947-5-1-14 |
| Dimensions (W x D x H) | 43 x 39.5 x 43 mm |
| Net Weight | 0.055 kg |
| Certifications | CE, UL, CSA, CB, CCC, DNV GL, EAC, GOST, RINA, LRS |
| RoHS Status | Compliant (EU Directive 2011/65/EU) |
