B&R 8LSA35-EA030D000-3 | Industrial Automation Component

SKU: 8LSA35-EA030D000-3
(1)
$6,083.34
In stock
Usually ships within 24 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 18017464056

Category: To Confirm

Synchronous motor 8LS, self-cooling, construction type A, 400 VAC - Number of pole pairs: 4 - Nominal speed: 3000 rpm - Nominal torque: 2.100 Nm - Stall torque: 2.300 Nm - Centering diameter: 80.00 mm, j6 fit - Flange square dimension: 91.30 mm - Brake holding torque: 0.00 Nm - Smooth shaft d=14.00 k6x30.00 mm, without oil seal - ECI 1319 ENDAT01, S: 1 - 00: No special option - Efficiency: 91.0.

Technical Specifications

General information

  • Certifications
  • CE = Yes
  • UKCA = Yes
  • CRA (Cyber Resilience Act) = In preparation
  • UL = cURus E360421 Servo and stepper motors - Component

Motor

  • Nominal speed n N [rpm] = 3000
  • Number of pole pairs = 4
  • Nominal torque M n [Nm] = 2.1
  • Nominal power P N [W] = 660
  • Nominal current I N [A] = 1.4
  • Stall torque M 0 [Nm] = 2.3
  • Stall current I 0 [A] = 1.6
  • Maximum torque M max [Nm] = 9.2
  • Maximum current I max [A] = 6.8
  • Maximum speed n max [rpm] = 9000
  • Torque constant K T [Nm/A] = 1.45
  • Voltage constant K E [V/1000 rpm] = 87.96
  • Stator resistance R 2ph [Ω] = 12.22
  • Stator inductance L 2ph [mH] = 63
  • Electrical time constant t el [ms] = 5.2
  • Thermal time constant t therm [min] = 34
  • Moment of inertia J [kgcm 2 ] = 0.9
  • Weight without brake m [kg] = 4.4

Holding brake

  • Holding torque of brake M Br [Nm] = 0
  • Mass of brake [kg] = 1.09
  • Moment of inertia of brake J Br [kgcm 2 ] = 0.38

Recommendations

  • ACOPOS 8Vxxxx.xx... = 1022
  • ACOPOSmulti 8BVIxxxx... = 0014
  • ACOPOS P3 8EIxxxx... = 2X2X
  • Cross section for B&R motor cables [mm 2 ] = 0.75
  • Connector size = 1

Options

  • Connection type = Connector (ytec system)
  • Connection direction = Angled (swivel)
  • Encoder = EA inductive 32-line single-turn V2
  • Shaft end = Smooth shaft
