SINUMERIK 828D numerical control CNC hardware PPU 271.4 horizontal maximum 4-axis interpolation
Product Type: Industrial Automation Component
General
| Article number |
6FC5370-5AA40-0AA0 |
General information
| product brand name |
SINUMERIK |
| product designation |
CNC control |
| product type designation |
828 |
| product short term |
PPU 271.4 |
Performance data
| consumed active power / maximum |
60 W |
| relative positive tolerance / at DC / at 24 V |
20 % |
| relative negative tolerance / at DC / at 24 V |
15 % |
| buffering time / in the event of power failure |
3 ms; 20 ms mit SITOP smart power supply |
Degree of protection and class of protection
| protection class IP / on the front |
IP65; With the front flap closed |
| protection class IP / rear side |
IP20 / UL open type |
Standards, approvals, certification
| reference code / according to IEC 81346-2 |
K |
Ambient conditions
| environmental category / according to IEC 60721-3-3 |
Class 3K5 Condensation and icing excluded. Low air temperature 0 °C (32 °F). |
| Substance Prohibitance (day/month/year) |
06/01/2018 |
| SVHC substance name |
Lead CAS-No. 7439-92-1
Lead monoxide (lead oxide) CAS-No. 1317-36-8
4,4'-isopropylidenediphenol (Bisphenol A, BPA) CAS-No. 80-05-7 |
Ambient temperature
| ● on the front / during operation |
0 ... 45, 32 ... 113 |
| ● rear side / during operation |
0 ... 55, 32 ... 131 |
| ● during transport |
-20 ... +60 °C, -4 ... +140 °F |
| ● during storage |
-25 ... +55 °C, -13 ... +131 °F |
Relative humidity
| ● at 25 °C / during operation |
5 ... 90 % |
| ● at 25 °C / during transport |
5 ... 95 % |
| ● at 25 °C / during storage |
10 ... 100 % |
Installation type/mounting / header
| mounting position / of operating panel |
Vertical |
Design, dimensions and weight
| width |
483 mm, 19.02 in |
| height |
220 mm, 8.66 in |
| depth |
105 mm, 4.13 in |
| net weight |
4.5 kg, 9.92 lb |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| Declaration of Conformity |
Yes |
| China RoHS |
Yes |
| UK Declaration of Conformity |
Yes |
| EU declaration of conformity |
Yes |
| China RoHS |
Yes |
| RCM |
Yes |
| KC |
Yes |
Functional Saftey
| Manufacturer Declaration |
Yes |
| TUEV |
Yes |
| Manufacturer Declaration |
Yes |
| Date8/3/2026 |
Subject to change without notice© Copyright Siemens 2026 |
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
