SINUMERIK 808D, extended M PPU 161.3 horizontal with current software version English layout maximum 4-axis interpolation
Product Type: Industrial Automation Component
General
| Article number |
6FC5370-2AM03-0AA0 |
General information
| product brand name |
SINUMERIK |
| product designation |
CNC control |
| product type designation |
808D |
| product short term |
PPU 161.3 |
Performance data
| consumed active power / maximum |
50 W |
| relative positive tolerance / at DC / at 24 V |
20 % |
| relative negative tolerance / at DC / at 24 V |
15 % |
| performance class for CNC controllers |
ADVANCED M |
| buffering time / in the event of power failure |
3 ms; 20 ms mit SITOP smart power supply |
Display
| design of the display |
LCD color |
| screen diagonal |
8.4 in |
| horizontal image resolution / of the display |
800 pixel |
| vertical image resolution / of the display |
600 pixel |
Degree of protection and class of protection
| protection class IP / on the front |
IP65; With the front flap closed |
| protection class IP / rear side |
IP20 / UL open type |
Standards, approvals, certification
| certificate of suitability |
CE, EAC, KC |
| reference code / according to IEC 81346-2 |
K |
Ambient conditions
| environmental category / according to IEC 60721-3-3 |
Condensation and icing excluded. Low air temperature 0 °C (32 °F). |
| Substance Prohibitance (day/month/year) |
08/04/2015 |
| SVHC substance name |
Lead CAS-No. 7439-92-1
Lead monoxide (lead oxide) CAS-No. 1317-36-8
4,4'-isopropylidenediphenol (Bisphenol A, BPA) CAS-No. 80-05-7 |
Ambient temperature
| ● on the front / during operation |
0 ... 45, 32 ... 113 |
| ● rear side / during operation |
0 ... 50, 32 ... 122 |
| ● during transport |
-20 ... +60 °C, -4 ... +140 °F |
| ● during storage |
-20 ... +60 °C, -4 ... +140 °F |
Relative humidity
| ● at 25 °C / during operation |
5 ... 90 % |
| ● at 25 °C / during transport |
5 ... 95 % |
| ● at 25 °C / during storage |
5 ... 95 % |
Installation type/mounting / header
| mounting position / of operating panel |
Vertical |
| positive cutout tolerance / of the mounting surface |
1 mm |
| cutout height / of the mounting surface |
186 mm ... 7.32 in |
| cutout width / of the mounting surface |
406 mm ... 15.98 in |
Design, dimensions and weight
| width |
420 mm, 16.54 in |
| height |
200 mm, 7.87 in |
| depth |
104 mm, 4.09 in |
| net weight |
3 kg, 6.61 lb |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| UNSPSC |
15 |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| Declaration of Conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| EU declaration of conformity |
Yes |
| China RoHS |
Yes |
| RCM |
Yes |
| KC |
Yes |
| Date8/3/2026 |
Subject to change without notice© Copyright Siemens 2026 |
