SINUMERIK ONE NCU 1740 with PLC-1500F
Product Type: Industrial Automation Component
General
| Article number |
6FC5317-4AA00-0AA0 |
General information
| product brand name |
SINUMERIK |
| product designation |
CNC control |
| product type designation |
ONE |
| product short term |
NCU 1740 |
Performance data
| type of voltage / of the supply voltage |
DC |
| supply voltage / at DC / rated value |
24 V |
| consumed current / rated value |
7 A |
| consumed current / maximum |
11 A |
| consumed active power / maximum |
315 W |
| power loss [W] / typical |
16 W |
Memory
| type of work memory 1 |
DRAM |
| ● storage capacity |
4 Gbyte |
| type of work memory 2 |
NVM |
| ● storage capacity |
1 Mbyte |
Degree of protection and class of protection
| protection class IP |
IP20; UL open type |
Standards, approvals, certification
| certificate of suitability |
CE, cULus, UKCA, EAC, RCM |
| reference code / according to IEC 81346-2 |
K |
Ambient conditions
| environmental category / according to IEC 60721-3-3 |
Condensation and icing excluded. Low air temperature 0 °C (32 °F). |
| Substance Prohibitance (day/month/year) |
08/04/2021 |
| SVHC substance name |
Lead CAS-No. 7439-92-1
Lead monoxide (lead oxide) CAS-No. 1317-36-8
4,4'-isopropylidenediphenol (Bisphenol A, BPA) CAS-No. 80-05-7
6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol CAS-No. 119-47-1 |
Ambient temperature
| ● during operation |
0 ... 55 °C, 32 ... 131 °F |
| ● during transport |
-40 ... +70 °C, -40 ... +158 °F |
| ● during storage |
-25 ... +55 °C, -13 ... +131 °F |
Relative humidity
| ● at 25 °C / during operation |
5 ... 95 % |
| ● at 25 °C / during transport |
5 ... 95 % |
| ● at 25 °C / during storage |
5 ... 95 % |
Design, dimensions and weight
| width |
50 mm, 1.97 in |
| height |
300 mm, 11.81 in |
| depth |
270 mm, 10.62 in |
| net weight |
2.4 kg, 5.29 lb |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
Environmental Product Declaration
| ● global warming potential [CO2 eq] / during manufacturing |
116 kg |
| ● global warming potential [CO2 eq] / during sales |
1.39 kg |
| ● global warming potential [CO2 eq] / during operation |
306 kg |
| ● global warming potential [CO2 eq] / after end of life |
-11.8 kg |
| ● global warming potential [CO2 eq] / total |
411.59 kg |
Environment
| EPD Typ II/III (with life cylce assessment) |
Yes |
| Siemens EcoTech Profile (SEP) |
Yes |
General Product Approval
| EU declaration of conformity |
Yes |
| Declaration of Conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| RCM |
Yes |
| EU declaration of conformity |
Yes |
| China RoHS |
Yes |
| UK Declaration of Conformity |
Yes |
| KC |
Yes |
Functional Saftey
| Manufacturer Declaration |
Yes |
| TUEV |
Yes |
| Manufacturer Declaration |
Yes |
Industrial Communication
| PROFINET |
Yes |
| Date8/3/2026 |
Subject to change without notice© Copyright Siemens 2026 |
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
