***No longer available*** SIMATIC IPC627C (Box PC), HD graphic onboard, 2x10/100/1000 Mbit/s Ethernet RJ45; 4 x USB V2.0 (high current); 1x serial (COM 1); RAID controller onboard; CompactFlash Drive No. 1 on front; Watchdog, temp./fan monitoring Celeron P4505 (2C/2T, 1.86 GHz, VT, 2 MB cache) 1 GB DDR3 1066 DIMM; 24 V DC industrial Power supply 2x PCI free 250 GB HDD SATA Windows XP Prof. SP3 MUI (de, en, fr, es, it) without expansion (software)
Product Type: Industrial Automation Component
General
| Article number |
6ES7647-6CA06-0AA0 |
Installation type/mounting
| Mounting |
Wall mounting, portrait mounting |
| Design |
Box PC, built-in unit |
Supply voltage
| Type of supply voltage |
100/240 V AC (autorange); 24 V DC |
Line frequency
| ● Rated value 50 Hz |
Yes |
| ● Rated value 60 Hz |
Yes |
Mains buffering
| ● Mains/voltage failure stored energy time |
20 ms |
Processor
| Processor type |
Core i7-610E (2C/4T, 2.53 GHz, TB, HT, VT, AMT, 4MB cache); Core i3-330E (2C/4T, 2.13 GHz, HT, VT, 3MB cache); Celeron P4505 (2C/2T, 1.86 GHz, VT, 2MB cache); |
| Chipset |
Intel QM57 Express Chipset |
Graphic
| Graphics controller |
Intel HD graphics controller |
Drives
| Optical drives |
DVD±R±RW combi-drive, optional |
| Hard disk |
3.5" SATA ≥ 250 GB, optional ≥ 500 GB; RAID1 2x 2.5" SATA ≥ 320 GB; all internal drives are vibration-damped |
| SSD |
Yes; ≥ 240 GB optional |
Storage
| Type of memory |
DDR3-1066 DIMM |
| Main memory |
1 / 2 / 4 / 8 GB; ECC optional |
| Capacity of main memory, max. |
8 Gbyte |
Data areas and their retentivity
| Retentive data area (incl. timers, counters, flags), max. |
2 Mbyte; 128 KB can be stored in the buffer time; optional |
Slots
| ● free slots |
2x PCI; optional: 1x PCI & 1x PCIe (x16); with card retainer |
| ● Number of PCI slots |
2 |
| ● Number of PCI slots |
1 |
| ● Number of compact flash slots |
1 |
Interfaces
| PROFIBUS/MPI |
Optionally onboard, isolated, max. 12 Mbit/s, compatible with CP 5611-A2 |
| Number of industrial Ethernet interfaces |
2; onboard |
| Number of PROFINET interfaces |
3; Optional |
| USB port |
4x USB 2.0 high speed/high current |
| Connection for keyboard/mouse |
USB / USB |
| parallel interface |
optional LPT1 |
Video interfaces
| ● Graphics interface |
DVI-I: VGA / DVI combined |
Industrial Ethernet
| ● Industrial Ethernet interface |
onboard, 2x 10 / 100 / 1 000 Mbit, RJ45 |
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Protocols (Ethernet)
Interrupts/diagnostics/status information
Monitoring functions
| ● Temperature monitoring |
Yes |
| ● Watchdog |
Yes |
| ● Fan |
Yes |
| ● Monitoring function via network |
Optional |
Interference immunity against discharge of static electricity
| ● Interference immunity against discharge of static electricity |
±6 kV contact discharge acc. to IEC 61000-4-2; ±8 kV air discharge acc. to IEC 61000-4-2 |
Interference immunity against high-frequency electromagnetic fields
| ● Interference immunity against high frequency radiation |
10 V/m for 80 - 1 000 MHz and 1.4 - 2 GHz, 80% AM acc. to IEC 61000-4-3; 3 V/m for 2 - 2.7 GHz, 80% AM acc. to IEC 61000-4-3; 10 V for 10 kHz - 80 MHz, 80% AM acc. to IEC 61000-4-6 |
Interference immunity to cable-borne interference
| ● Interference immunity on supply cables |
±2 kV acc. to IEC 61000-4-4, burst; ±1 kV acc. to IEC 61000-4-5, surge symmetric; ±2 kV acc. to IEC 61000-4-5, surge asymmetric |
| ● Interference immunity on signal cables >30m |
±2 kV acc. to IEC 61000-4-5, surge, length > 30 m |
| ● Interference immunity on signal cables < 30m |
±1 kV acc. to IEC 61000-4-4; burst; length < 3 m; ±2 kV acc. to IEC 61000-4-4; burst; length > 3 m |
Interference immunity against voltage surge
| ● asymmetric interference |
±2 kV acc. to IEC 61000-4-5, surge asymmetric |
| ● symmetric interference |
±1 kV acc. to IEC 61000-4-5, surge symmetric |
Interference immunity to magnetic fields
| ● Interference immunity to magnetic fields at 50 Hz |
100 A/m; to IEC 61000-4-8 |
Emission of conducted and non-conducted interference
| ● Interference emission via line/AC current cables |
EN 61000-6-3, EN 61000-6-4, CISPR 22 Class B, FCC Class A |
Degree and class of protection
| IP degree of protection |
IP20 |
| IP (at the front) |
IP20 |
| IP (rear) |
IP20 |
Standards, approvals, certificates
| CE mark |
Yes |
| UL approval |
Yes |
| ● UL 508 |
Yes |
| cULus |
Yes |
| RCM (formerly C-TICK) |
Yes |
| KC approval |
Yes |
| FCC |
Yes |
| EMC |
CE, EN 61000-6-3:2007 +A1:2011, EN 61000-6-2:2005 |
Marine approval
| ● Germanischer Lloyd (GL) |
Yes |
| ● American Bureau of Shipping (ABS) |
Yes |
| ● Bureau Veritas (BV) |
Yes |
| ● Det Norske Veritas (DNV) |
Yes |
| ● Lloyds Register of Shipping (LRS) |
Yes |
| ● Nippon Kaiji Kyokai (Class NK) |
Yes |
Ambient temperature during operation
Ambient temperature during storage/transportation
| ● min. |
-20 °C |
| ● max. |
60 °C |
Relative humidity
| ● Relative humidity |
Tested according to IEC 60068-2-78, IEC 60068-2-30: Operation: 5% to 80% at 25 °C (no condensation), Storage: 5% to 95% at 25 °C (no condensation) |
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
tested to DIN IEC 60068-2-6: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 200 Hz: 9.8 m/s² (1 g) |
Shock testing
| ● Shock load during operation |
Tested to DIN IEC 60068-2-29: 50 m/s² (5 g), 30 ms, 100 shocks |
Operating systems
| pre-installed operating system |
Windows XP Prof. SP3, MUI; Windows 7 Ultimate 32-bit / 64-bit, MUI; Windows Embedded Standard 2009 English on 8 GB CompactFlash; without operating system |
| without operating system |
Yes |
pre-installed operating system
| ● Windows XP Professional |
Yes |
| ● Windows 7 |
Yes; Ultimate 32 bit or 64 bit |
Software
| SIMATIC Software |
Optional package with SIMATIC WinCC or WinAC RTX |
Dimensions
| Width |
312 mm |
| Height |
80 mm; with DVD drive: 100 mm |
| Depth |
301 mm; incl. mounting rail |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
General Product Approval
| Manufacturer Declaration |
Yes |
| Miscellaneous |
Yes |
| UL |
Yes |
| KC |
Yes |
| China RoHS |
Yes |
Maritime application
| ABS (American Bureau of Shipping) |
Yes |
| BV (Bureau Veritas) |
Yes |
| CCS (China Classification Society) |
Yes |
| KR (Korean Register of Shipping) |
Yes |
Dangerous goods
| Dangerous goods information |
Yes |
| Test Summary Report UN 38.3 |
Yes |
| last modified: |
11/25/2025 |
