SIMATIC IOT2050; 2x Gbit Ethernet RJ45; Display port; 2x USB2.0; 16 GB eMMC; SD card slot; 24 V DC industrial power supply
Product Type: Industrial Automation Component
General
| Article number |
6ES7647-0BA00-1YA2 |
General information
| Product type designation |
IOT2050 |
Installation type/mounting
| Design |
IoT Gateway, built-in unit |
Supply voltage
| Type of supply voltage |
12/24 V DC |
Mains buffering
| ● Mains/voltage failure stored energy time |
5 ms |
Processor
| Processor type |
ARM TI AM6548 HS |
Graphic
| Graphics controller |
Integrated |
| Graphics card |
Yes |
Drives
| Slot for drives |
1x microSD card slot |
Storage
| Type of memory |
DDR4 |
| Main memory |
2 GB RAM |
| Capacity of main memory, max. |
2 Gbyte |
Digital inputs
| Number of digital inputs |
20 |
Input voltage
| ● Type of input voltage |
DC |
Digital outputs
| Number of digital outputs |
20 |
Output voltage
| ● Type of output voltage |
DC |
| ● permissible voltage at output, min. |
3.3 V |
| ● permissible voltage at output, max. |
5 V |
Analog inputs
| Number of analog inputs |
6 |
Input ranges
Interfaces
| Number of industrial Ethernet interfaces |
2 |
| Number of PROFINET interfaces |
2 |
| serial interface |
1x COM (1x RS 232 / 422 / 485) |
Video interfaces
| ● Graphics interface |
1x DisplayPort |
● Industrial Ethernet interface
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Interrupts/diagnostics/status information
Monitoring functions
| ● Temperature monitoring |
Yes |
Degree and class of protection
| IP degree of protection |
IP20 |
| IP (all-round) |
IP20 |
Standards, approvals, certificates
| CE mark |
Yes |
| UL approval |
Yes |
| cULus |
Yes |
| RCM (formerly C-TICK) |
Yes |
| KC approval |
Yes |
| EAC (formerly Gost-R) |
Yes |
| FCC |
Yes |
Ecological footprint
| ● environmental product declaration |
Yes |
Global warming potential
| — global warming potential, (total) [CO2 eq] |
196 kg |
| — global warming potential, (during production) [CO2 eq] |
18.7 kg |
| — global warming potential, (during operation) [CO2 eq] |
179 kg |
| — global warming potential, (after end of life cycle) [CO2 eq] |
-2.28 kg |
Ambient temperature during operation
Ambient temperature during storage/transportation
| ● min. |
-20 °C |
| ● max. |
70 °C |
Altitude during operation relating to sea level
| ● Installation altitude above sea level, max. |
2 000 m |
Relative humidity
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
tested according to IEC 60068-2-6: 10 cycles; 5 to 8.4 Hz: deflection 3.5 mm; 8.4 to 200 Hz: acceleration 9.8 m/s² |
Operating systems
| pre-installed operating system |
SIMATIC Industrial OS |
| without operating system |
No |
Mechanics/material
| Enclosure material (front) |
plastic |
| ● Plastic |
Yes |
| ● Aluminum |
Yes |
| ● Stainless steel |
Yes |
| ● Glass |
No |
Dimensions
| Width |
37 mm |
| Height |
142 mm |
| Depth |
100 mm |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| Manufacturer Declaration |
Yes |
| RCM |
Yes |
| UL |
Yes |
| EAC |
Yes |
| KC |
Yes |
Dangerous goods
| Dangerous goods information |
Yes |
| Dangerous goods information |
Yes |
| Test Summary Report UN 38.3 |
Yes |
Environment
| EPD Typ II/III (with life cylce assessment) |
Yes |
| last modified: |
11/25/2025 |
