SIMATIC S7-200 SMART, PROFIBUS DP Slave module, 9.6 KB to 12 MB, 1 interface PROFIBUS-DP/MPI
Product Type: Industrial Automation Component
General
| Article number |
6ES7288-7DP01-0AA0 |
General information
| Product type designation |
EM DP01, PROFIBUS DP slave module |
Supply voltage
| Type of supply voltage |
DC |
| Rated value (DC) |
24 V |
| permissible range, lower limit (DC) |
20.4 V |
| permissible range, upper limit (DC) |
28.8 V |
Input current
| Current consumption, typ. |
15 mA |
| Current consumption, max. |
30 mA |
Power loss
Interfaces
| Number of industrial Ethernet interfaces |
0 |
| Number of RS 485 interfaces |
1 |
Protocols
| Supports protocol for PROFINET IO |
No |
| PROFIBUS |
Yes |
Protocols (Ethernet)
Dimensions
| Width |
45 mm |
| Height |
100 mm |
| Depth |
81 mm |
Weights
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| EAC |
Yes |
| China RoHS |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| last modified: |
3/12/2024 |
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
