SIMATIC S7-200 SMART, analog I/O SM AM06, 2AI/1AO, 0..10V,0..5V, 0/4..20mA, +/-5 V, +/-2.5 V, 12 bit resolution or 4...20 mA, +/-10 V, 11 bit resolution
Product Type: Industrial Automation Component
General
| Article number |
6ES7288-3AM03-0AA0 |
General information
| Product type designation |
SM AM03, AI 2x12 bit, AQ 1x11 bit |
Power loss
Analog inputs
| Number of analog inputs |
2 |
Input ranges
| ● Voltage |
Yes |
| ● Current |
Yes |
| ● Thermocouple |
No |
| ● Resistance thermometer |
No |
| ● Resistance |
No |
Analog outputs
| Number of analog outputs |
1 |
Integration and conversion time/resolution per channel
| ● Resolution with overrange (bit including sign), max. |
12 bit |
| ● Resolution with overrange (bit including sign), max. |
11 bit |
Dimensions
| Width |
45 mm |
| Height |
100 mm |
| Depth |
81 mm |
Weights
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| EAC |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| China RoHS |
Yes |
| last modified: |
3/12/2024 |
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
