SIMATIC PM207/1AC/24VDC/3ASIMATIC S7-200 smart Regulated power supply input: 100-240 V AC output: 24 V/3 A DC
Product Type: Industrial Automation Component
General
| Article number |
6ES7288-0CD10-0AA0 |
General information
| Technical Product Detail Page |
https://i.siemens.com/1P6ES7288-0CD10-0AA0 |
input
| type of the power supply network |
1-phase AC |
supply voltage at AC
| ● minimum rated value |
100 V |
| ● maximum rated value |
240 V |
| ● initial value |
85 V |
| ● full-scale value |
264 V |
| input voltage at DC |
88 ... 370 V |
| wide range input |
Yes |
| buffering time for rated value of the output current in the event of power failure minimum |
20 ms |
| operating condition of the mains buffering |
at Vin = 170 V |
| line frequency |
50/60 Hz |
| line frequency |
47 ... 63 Hz |
input current
| ● at rated input voltage 120 V |
1.65 A |
| ● at rated input voltage 230 V |
0.75 A |
| current limitation of inrush current at 25 °C maximum |
30 A |
| I2t value maximum |
1.5 A²·s |
| fuse protection type |
internal |
| fuse protection type in the feeder |
Recommended miniature circuit breaker: 10 A characteristic C |
output
| voltage curve at output |
Controlled, isolated DC voltage |
| output voltage at DC rated value |
24 V |
| output voltage adjustable |
Yes; via potentiometer |
| adjustable output voltage |
22.8 ... 26.4 V |
| relative overall tolerance of the voltage |
0.5 % |
relative control precision of the output voltage
| ● on slow fluctuation of input voltage |
0.1 % |
| ● on slow fluctuation of ohm loading |
0.5 % |
voltage peak
| ● maximum |
50 mV |
| ● typical |
25 mV |
| display version for normal operation |
Green LED for 24 V OK |
| behavior of the output voltage when switching on |
Overshoot of Vout < 1 % |
| response delay maximum |
0.5 s |
voltage increase time of the output voltage
output current
| ● rated value |
3 A |
| ● rated range |
0 ... 3 A; +55 ... +70 °C: Derating 3.5%/K |
| supplied active power typical |
72 W |
| bridging of equipment |
Yes |
| number of parallel-switched equipment resources for increasing the power |
2 |
efficiency
| efficiency in percent |
89 % |
power loss [W]
| ● at rated output voltage for rated value of the output current typical |
9 W |
closed-loop control
| relative control precision of the output voltage at load step of resistive load 10/90/10 % typical |
3 % |
setting time
| ● load step 10 to 90% typical |
1 ms |
| ● load step 90 to 10% typical |
1 ms |
protection and monitoring
| design of the overvoltage protection |
< 28.8 V |
| property of the output short-circuit proof |
Yes |
| design of short-circuit protection |
Constant current characteristic |
| response value current limitation |
3.6 ... 4.4 A |
| ● typical |
4 A |
enduring short circuit current RMS value
safety
| galvanic isolation between input and output |
Yes |
| galvanic isolation |
Output voltage: SELV |
| operating resource protection class |
Class I |
leakage current
| ● maximum |
3.5 mA |
| protection class IP |
IP20 |
standard
| ● for emitted interference |
EN 55022 Class B |
| ● for mains harmonics limitation |
EN 61000-3-2 |
| ● for interference immunity |
EN 61000-6-2 |
certificate of suitability
| ● CE marking |
Yes |
| ● UL approval |
Yes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259 |
| ● UKCA marking |
No |
| ● EAC approval |
No |
| ● Regulatory Compliance Mark (RCM) |
No |
| ● CCC approval |
Yes |
| ● NEC Class 2 |
No |
| ● IECEx |
No |
| ● ATEX |
No |
| ● ULhazloc approval |
No |
| ● FM registration |
No |
type of certification
| ● BIS |
Yes; R-41184349 |
| ● CB-certificate |
Yes |
| MTBF at 40 °C |
500 000 h |
| MTBF at 25 °C |
according to MIL-HDBK-217F, 100% full load (24 V, 3 A), input voltage: 220 V AC |
standards, specifications, approvals marine classification
Marine classification association
| ● American Bureau of Shipping Europe Ltd. (ABS) |
No |
| ● French marine classification society (BV) |
No |
| ● Det Norske Veritas (DNV) |
No |
| ● Lloyds Register of Shipping (LRS) |
No |
ambient temperature
| ● during operation |
-25 ... +70 °C; With natural convection |
| ● during transport |
-40 ... +85 °C |
| ● during storage |
-40 ... +85 °C |
| environmental category according to IEC 60721 |
Climate class 3K3, 5 ... 95% no condensation |
connection method
| type of electrical connection |
screw terminal |
| ● at input |
L, N, PE: screw terminal for 0.5 ... 6 mm² single-core / 0.5 ... 4 mm² finely stranded |
| ● at output |
+1, +2, -1, -2: screw terminal for 0.5 ... 4 mm² |
mechanical data
| width × height × depth of the enclosure |
45 × 100 × 81 mm |
| installation width × mounting height |
85 mm × 140 mm |
required spacing
| ● top |
20 mm |
| ● bottom |
20 mm |
| ● left |
20 mm |
| ● right |
20 mm |
| fastening method |
Snaps onto DIN rail EN 60715 35x7.5/15 |
| ● DIN-rail mounting |
Yes |
| ● S7 rail mounting |
No |
| ● wall mounting |
Yes |
| housing can be lined up |
No |
| net weight |
0.46 kg |
additional information
| other information |
Specifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified) |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| Manufacturer Declaration |
Yes |
| EU declaration of conformity |
Yes |
| last modified: |
5/5/2026 |
| Date8/3/2026 |
Subject to change without notice© Copyright Siemens 2026 |
