*** Spare part *** SIMATIC DP, Electronics module f. ET200S, 2 AO U, 15 mm width, +/-10V; 13 bit+sign, 1..5 V; 12 bit, Cycle time less than 1 ms with SF LED (group fault)
Product Type: Industrial Automation Component
General
| Article number |
6ES7135-4FB01-0AB0 |
Product function
Load voltage L+
| ● Rated value (DC) |
24 V; From power module |
| ● Reverse polarity protection |
Yes |
Input current
| from load voltage L+ (without load), max. |
130 mA |
| from backplane bus 3.3 V DC, max. |
10 mA |
Address space per module
| ● Address space per module, max. |
4 byte |
Analog outputs
| Number of analog outputs |
2 |
| Voltage output, short-circuit protection |
Yes |
| Voltage output, short-circuit current, max. |
25 mA |
| Cycle time (all channels) max. |
1.5 ms |
Output ranges, voltage
| ● 1 V to 5 V |
Yes |
| ● -10 V to +10 V |
Yes |
Connection of actuators
| ● for voltage output two-wire connection |
Yes; Without compensation of the line resistances |
| ● for voltage output four-wire connection |
Yes |
Load impedance (in rated range of output)
| ● with voltage outputs, min. |
1 kΩ |
| ● with voltage outputs, capacitive load, max. |
1 µF |
Destruction limits against externally applied voltages and currents
| ● Voltages at the outputs towards MANA |
15 V; max. 15 V continuous; 75 V for max. 1 s (mark to space ratio 1:20) |
| ● Current, max. |
50 mA; DC |
Cable length
Integration and conversion time/resolution per channel
| ● Resolution with overrange (bit including sign), max. |
14 bit; 1 to 5 V: 12 bit, ±10 V: 13 bit + sign |
Settling time
| ● for resistive load |
0.1 ms |
| ● for capacitive load |
0.5 ms |
| ● for inductive load |
0.5 ms |
Operational error limit in overall temperature range
| ● Voltage, relative to output range, (+/-) |
0.4 % |
Basic error limit (operational limit at 25 °C)
| ● Voltage, relative to output range, (+/-) |
0.2 % |
Interrupts/diagnostics/status information
| Substitute values connectable |
Yes; 0 to 65535 (range of values must be within the rated range) |
Diagnoses
| ● Diagnostic information readable |
Yes |
| ● Short-circuit |
Yes |
| ● Group error |
Yes |
Diagnostics indication LED
| ● Group error SF (red) |
Yes |
Potential separation analog outputs
| ● between the channels |
No |
| ● between the channels and backplane bus |
Yes |
| ● Between the channels and load voltage L+ |
Yes |
Isolation
| Isolation tested with |
500 V DC |
Dimensions
| Width |
15 mm |
| Height |
81 mm |
| Depth |
52 mm |
Weights
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| Miscellaneous |
Yes |
| Manufacturer Declaration |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| UL |
Yes |
| RCM |
Yes |
| EAC |
Yes |
| China RoHS |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| RCM |
Yes |
For use in hazardous locations
| ATEX |
Yes |
| FM |
Yes |
| ATEX |
Yes |
| UL |
Yes |
| ATEX |
Yes |
| IECEx |
Yes |
| Miscellaneous |
Yes |
| CCC-Ex |
Yes |
Maritime application
| ABS (American Bureau of Shipping) |
Yes |
| BV (Bureau Veritas) |
Yes |
| DNV (Det Norske Veritas) |
Yes |
| LR (Lloyds Register) |
Yes |
| NK / Nippon Kaiji Kyokai |
Yes |
| PRS (Polski Register of Shipping) |
Yes |
| RINA (Registro Italiano Navale) |
Yes |
| CCS (China Classification Society) |
Yes |
| last modified: |
8/22/2025 |
