*** Spare part *** SIMATIC DP, 5 electronic modules for ET 200S, 4DI standard 24 V DC, 15 mm width, 5 units per packing unit
Product Type: Industrial Automation Component
General
| Article number |
6ES7131-4BD01-0AA0 |
Supply voltage
| Rated value (DC) |
24 V; From power module |
| Reverse polarity protection |
Yes |
Input current
| from supply voltage L+, max. |
Dependent on encoder |
| from backplane bus 3.3 V DC, max. |
10 mA |
| ● for signal "1", typ. |
7 mA; at 24 V |
Encoder supply
| Type of output voltage |
min. L+ (-0.5 V), under load |
Output current
| ● Rated value |
500 mA |
| ● permissible range, lower limit |
0 mA |
| ● permissible range, upper limit |
500 mA |
Power loss
Address space per module
| ● Address space per module, max. |
1 byte |
| ● with packing |
4 bit |
Digital inputs
| Number of digital inputs |
4 |
| Input characteristic curve in accordance with IEC 61131, type 1 |
Yes |
Input voltage
| ● Type of input voltage |
DC |
| ● Rated value (DC) |
24 V |
| ● for signal "0" |
-30 to +5 V |
| ● for signal "1" |
+15 to +30 V |
for standard inputs
| — parameterizable |
No |
| — at "0" to "1", min. |
2 ms; typically 3 ms |
| — at "0" to "1", max. |
4.5 ms |
| — at "1" to "0", min. |
2 ms; typically 3 ms |
| — at "1" to "0", max. |
4.5 ms |
Cable length
| ● shielded, max. |
1 000 m |
| ● unshielded, max. |
600 m |
Connectable encoders
| ● 2-wire sensor |
Yes |
| — permissible quiescent current (2-wire sensor), max. |
1.5 mA |
Interrupts/diagnostics/status information
Diagnostics indication LED
| ● Group error SF (red) |
No |
| ● Status indicator digital input (green) |
Yes; per channel |
Potential separation digital inputs
| ● between the channels |
No |
| ● between the channels and backplane bus |
Yes |
Isolation
| Isolation tested with |
500 V DC |
Dimensions
| Width |
15 mm |
| Height |
81 mm |
| Depth |
52 mm |
Weights
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
other
| Confirmation |
Yes |
| Chinese Quality Checkmark |
Yes |
Environment
| Environmental Confirmations |
Yes |
| last modified: |
8/22/2025 |
Applications
