SITOP PSU400S/DC/DC/48V/24V/5A********* spare part ********** SITOP PSU400S 24 V/5 A stabilized power supply input: 48 V DC (30.2...75 V) output: 24 V DC/5 A (22...28V)
Product Type: Industrial Automation Component
General
| Article number |
6EP1733-2BA00-0AA0 |
input
| type of the power supply network |
DC voltage |
| input voltage at DC |
30 ... 75.5 V |
| buffering time for rated value of the output current in the event of power failure minimum |
5 ms |
| operating condition of the mains buffering |
at Vin = 48 V |
input current
| ● at rated input voltage 48 V |
2.9 A |
| fuse protection type in the feeder |
6 A characteristic C |
output
| voltage curve at output |
Controlled, isolated DC voltage |
| output voltage at DC rated value |
24 V |
output voltage
| ● at output 1 at DC rated value |
24 V |
| output voltage adjustable |
Yes; via potentiometer |
| adjustable output voltage |
22.8 ... 28 V; max. 120 W |
| relative overall tolerance of the voltage |
3 % |
residual ripple
voltage peak
| ● maximum |
200 mV |
| display version for normal operation |
Green LED for 24 V OK |
| type of signal at output |
No |
| response delay maximum |
2.5 s |
voltage increase time of the output voltage
output current
| ● rated value |
5 A |
| ● rated range |
0 ... 5 A; +60 ... +70 °C: Derating 2.5%/K |
| supplied active power typical |
120 W |
| bridging of equipment |
Yes |
| number of parallel-switched equipment resources for increasing the power |
2 |
efficiency
| efficiency in percent |
89 % |
power loss [W]
| ● at rated output voltage for rated value of the output current typical |
5 W |
setting time
protection and monitoring
| design of the overvoltage protection |
< 33 V |
| property of the output short-circuit proof |
Yes |
overcurrent overload capability
| ● in normal operation |
overload capability 150 % Iout rated up to 5 s/min |
safety
| galvanic isolation between input and output |
Yes |
| galvanic isolation |
Safety extra low output voltage Vout according to EN 60950-1 |
standard
| ● for emitted interference |
EN 61000-6-3 Class A |
| ● for interference immunity |
EN 61000-6-2 |
certificate of suitability
| ● CE marking |
Yes |
| ● UL approval |
Yes; UL 508, CSA C22.2 No. 107.1 |
| ● EAC approval |
Yes |
| ● NEC Class 2 |
No |
| MTBF at 40 °C |
500 000 h |
| ● IECEx |
No |
| ● ATEX |
No |
| ● ULhazloc approval |
No |
| ● FM registration |
No |
standards, specifications, approvals marine classification
Marine classification association
| ● American Bureau of Shipping Europe Ltd. (ABS) |
No |
| ● French marine classification society (BV) |
No |
| ● Det Norske Veritas (DNV) |
No |
| ● Lloyds Register of Shipping (LRS) |
No |
ambient temperature
| ● during operation |
-25 ... +70 °C; with natural convection |
| ● during transport |
-40 ... +85 °C |
| ● during storage |
-40 ... +85 °C |
| environmental category according to IEC 60721 |
Climate class 3K3, 5 ... 95% no condensation |
connection method
| type of electrical connection |
screw terminal |
| ● at input |
+, -: 1 screw terminal each for 0.2 ... 2.5 mm² |
| ● at output |
+, -: 2 screw terminals each for 0.2 ... 2.5 mm² |
mechanical data
| width × height × depth of the enclosure |
50 × 125 × 125 mm |
| installation width × mounting height |
50 mm × 225 mm |
required spacing
| ● top |
50 mm |
| ● bottom |
50 mm |
| ● left |
0 mm |
| ● right |
0 mm |
| fastening method |
Snaps onto DIN rail EN 60715 35x7.5/15 |
| ● DIN-rail mounting |
Yes |
| ● S7 rail mounting |
No |
| ● wall mounting |
No |
| housing can be lined up |
Yes |
| net weight |
0.5 kg |
accessories
| electrical accessories |
Redundancy module, buffer module, diagnostics module SITOP select, DC UPS |
internet link
| ● to website: Industry Mall |
https://mall.industry.siemens.com |
| ● to web page: selection aid TIA Selection Tool |
https://www.siemens.com/tstcloud |
| ● to website: CAx-Download-Manager |
https://siemens.com/cax |
| ● to website: Industry Online Support |
https://support.industry.siemens.com |
additional information
| other information |
Specifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified) |
security information
| security information |
Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement - and continuously maintain - a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are industrial. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7) |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| Manufacturer Declaration |
Yes |
| EU declaration of conformity |
Yes |
| China RoHS |
Yes |
| UL |
Yes |
| last modified: |
3/26/2026 |
| Date8/3/2026 |
Subject to change without notice© Copyright Siemens 2026 |
