***no longer available*** SIMATIC HMI IPC 577C PCI slot, 4 USB (back)+1 USB (front), Ethernet (10/100/1000), 19" touch display ; Core 2 Duo 1.86 GHz, PROFIBUS DP 12; 2x 1 Gbit 4 GB -RAM, DDR3; 2nd mass storage: DVD RW 1st mass storage (Operating system optional): 320 GB HDD SATA Windows 7 Ultimate MUI pre-installed; (only possible with HD or SSD) without expansion (software) 110/230 V AC power supply unit with NAMUR, Power supply cable UK
Product Type: Industrial Automation Component
General
| Article number |
6AV7885-5AL31-1GA7 |
General information
| Product type designation |
IPC577C |
Display
| Design of display |
19" TFT touch |
| Screen diagonal |
19 in |
Resolution (pixels)
| ● Horizontal image resolution |
1 280 pixel |
| ● Vertical image resolution |
1 024 pixel |
Backlighting
| ● MTBF backlighting (at 25 °C) |
50 000 h |
Input device
| ● Integrated mouse cursor control |
No |
| ● Mouse, at front |
No |
Keyboard
| ● Function keys |
No |
| — Number of function keys |
0 |
| ● alphanumeric keyboard |
No |
Touch operation
| ● Design as touch screen |
Yes |
Installation type/mounting
| central design |
Yes |
| distributed design |
No |
| maximum permissible installation angle +/- |
45° |
Supply voltage
| Type of supply voltage |
110/230 V AC or 24 V DC |
Power loss
| In full configuration |
24 V DC: max. 80 W (incl. USB interfaces) |
Processor
| Processor type |
Intel Celeron M 1.2 GHz, Intel Core2Solo 1.2 GHz, Intel Core2Duo 1.86 GHz |
Drives
| Optical drives |
Optional: DVD±R±RW combi drive; on rear, can be operated from side |
| Hard disk |
3.5" SATA hard disk ≥ 80 GB, vibration-resistant mounting |
Storage
| Type of memory |
DDR3-SDRAM |
| Main memory |
512 MB |
| Capacity of main memory, max. |
4 096 Mbyte; At least 3.2 GB can be industrial |
Data areas and their retentivity
| Retentive data area (incl. timers, counters, flags), max. |
2 048 kbyte; 128 KB can be stored in the buffer time |
Slots
| ● free slots |
1x CF card slot, externally accessible, 1x PCI slot in device interior, 1x SSD slot |
| ● Number of PCI slots |
1 |
| ● Number of compact flash slots |
1 |
Interfaces
| USB port |
1x on front, 4x on reverse, USB 2.0 (3x 500 mA) |
| Connection for keyboard/mouse |
USB / USB |
| parallel interface |
0 |
Multimedia
| ● Audio In/Out |
No |
| ● Microphone In |
No |
Video interfaces
| ● Graphics interface |
DVI-I: VGA / DVI combined |
Industrial Ethernet
| ● Industrial Ethernet interface |
PROFIBUS version, onboard 2 x: PROFINET version, onboard 1 x: 10/100/1000 Mbit/s, RJ45, no plug-in card necessary. |
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Protocols (Ethernet)
Monitoring functions
| ● Temperature monitoring |
Yes |
| ● Watchdog |
Yes |
Degree and class of protection
Standards, approvals, certificates
| CE mark |
Yes |
| EMC |
CE, EN 61000-6-4; CISPR 22:2004 Class A; FCC Class A |
Use in hazardous areas
| ● FM Class I Division 2 |
No |
Marine approval
| ● Germanischer Lloyd (GL) |
No |
| ● American Bureau of Shipping (ABS) |
No |
| ● Bureau Veritas (BV) |
No |
| ● Det Norske Veritas (DNV) |
No |
| ● Lloyds Register of Shipping (LRS) |
No |
| ● Polski Rejestr Statkow (PRS) |
No |
Ambient temperature during operation
Relative humidity
| ● Relative humidity |
Tested according to IEC 60068-2-78, IEC 60068-2-30: Operation: 5% to 85% at 30 °C (no condensation) Storage: 5% to 95% at 25 °C (no condensation) |
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
Mech. environmental conditions tested in acc. with IEC 60068-2-6 Vibration: in operation with CompactFlash Card and SSD: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 500 Hz: 9.8 m/s²; in operation with HDD: 10 Hz to 58 Hz: 0.0375 mm, 58 Hz to 500 Hz: 4.9 m/s² |
Shock testing
| ● Shock load during operation |
Tested according to DIN IEC 60068-2-7: 50 m/s² (5 g), 30 ms |
Operating systems
| pre-installed operating system |
Windows XP Embedded and Win XP Prof. |
| Additional info on operating system |
WIN XPe: GER/ENG WIN XP Prof: MUI Language: GER, ENG, IT, FR, SP, KOR, CHN (traditional), CHN (simplified), JPN |
| without operating system |
Yes |
pre-installed operating system
| ● Windows XP Professional |
Yes; Only with SSD or HDD |
Accessories
| Accessory components |
Touch protective foil |
Dimensions
| Width of the housing front |
483 mm |
| Height of housing front |
400 mm |
| Mounting cutout, width |
450 mm |
| Mounting cutout, height |
380 mm |
| mounting depth |
125 mm |
| ● additional mounting depth (optical drive) |
23 mm |
Weights
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| KC |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| RCM |
Yes |
Dangerous goods
| Dangerous goods information |
Yes |
| Test Summary Report UN 38.3 |
Yes |
| last modified: |
2/16/2021 |
