**** no longer available **** SIMATIC HMI IPC 477C pro optional bundle with WinCC flexible 2008/WinAC, 19" Touch Display; fully protected IP65, 4 USB (back) Standard front Core 2 Duo 1.2 GHz, PROFINET (IE); 2x 1 Gbit 1 GB -RAM, DDR3; 2nd CF slot not equipped CF card: 2 GB Windows Embedded Standard 2009 pre-installed without SIMATIC software
Product Type: Industrial Automation Component
General
| Article number |
6AV7883-7AG10-2BA0 |
Supply voltage
| Type of supply voltage |
24 V DC |
Processor
| Processor type |
Intel Celeron M 1.2 GHz, Intel Core2Solo 1.2 GHz or Intel Core2Duo 1.2 GHz |
Drives
| Optical drives |
possible as external drive via USB |
Storage
| Type of memory |
DDR3-SDRAM |
| Main memory |
512 MB |
| Capacity of main memory, max. |
4 096 Mbyte; At least 3.2 GB can be industrial |
Slots
| ● Number of PCI slots |
0 |
| ● Number of compact flash slots |
1 |
Interfaces
| serial interface |
COM1: 1x V.24 (RS 232) |
Video interfaces
| ● Graphics interface |
DVI-I usable for additional display unit (VGA via adapter); color depth 32 bit, 8 to 128 MB Shared Memory |
● Industrial Ethernet interface
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Protocols (Ethernet)
Interrupts/diagnostics/status information
Monitoring functions
| ● Temperature monitoring |
Yes |
Degree and class of protection
| IP (at the front) |
IP65 (on front) to EN60529 and NEMA4 |
Marine approval
| ● Germanischer Lloyd (GL) |
Yes |
| ● American Bureau of Shipping (ABS) |
Yes |
| ● Bureau Veritas (BV) |
Yes |
| ● Det Norske Veritas (DNV) |
Yes |
| ● Lloyds Register of Shipping (LRS) |
Yes |
| ● Polski Rejestr Statkow (PRS) |
Yes |
Ambient temperature during operation
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
tested to DIN IEC 60068-2-6: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 200 Hz: 9.8 m/s² (1 g) |
Operating systems
| pre-installed operating system |
Windows XP Prof. (Multi-Language), Windows XP embedded or optionally without operating system |
pre-installed operating system
| ● Windows XP Professional |
Yes |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| Miscellaneous |
Yes |
| KC |
Yes |
| China RoHS |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| RCM |
Yes |
Dangerous goods
| Dangerous goods information |
Yes |
| Test Summary Report UN 38.3 |
Yes |
| last modified: |
11/25/2025 |
