Extension unit 15" hardwired for mounting on all fully IP65-enclosed 16:9 HMI/IPC devices. For the flexible installation of operator controls, 8 mounting positions, 8 operator controls equippable; connection via hardwired connection (without equipment)
Product Type: Industrial Automation Component
General
| Article number |
6AV7674-1LA41-0AA0 |
General information
| Product type designation |
Extension Unit 15" hardwired |
Connection type
| ● Connection type of the LED module |
12-pin connector |
| ● Connection type of the contacts of the control elements |
16-pin connector |
| ● Connection type of the safety-related contacts (emergency stop) |
8-pin connector |
Installation type/mounting
| Mounting |
For mounting on a 16:9 HMI / IPC PRO device (lower part) |
| Mounting type |
Screwed joint |
| Rack mounting |
No |
| Front mounting |
No |
| Number of slots for command devices and signaling units |
8 |
Supply voltage
| Type of supply voltage |
DC |
| Rated value (DC) |
24 V |
| permissible range, lower limit (DC) |
19.2 V |
| permissible range, upper limit (DC) |
28.8 V |
Input current
| Current consumption (rated value) |
10 mA; without load |
Power
| Active power input, typ. |
0.1 W |
| Emitted active power |
5 W |
Degree and class of protection
NEMA (front)
| ● Enclosure Type 4 at the front |
Yes |
Standards, approvals, certificates
| CE mark |
Yes |
| UL approval |
Yes |
| cULus |
Yes |
| RCM (formerly C-TICK) |
Yes |
| KC approval |
Yes |
| Suitable for safety functions |
Yes; e.g. installation of emergency stop |
Ambient temperature during operation
Ambient temperature during storage/transportation
| ● min. |
-20 °C |
| ● max. |
60 °C |
Altitude during operation relating to sea level
| ● Installation altitude above sea level, max. |
2 000 m |
Relative humidity
| ● Operation, max. |
90 %; no condensation |
Cables
Material
Enclosure material (front)
| ● Aluminum |
Yes; Knockout covered with black film |
Dimensions
| Width |
396 mm |
| Height |
99 mm |
| Thickness |
100.65 mm |
Weights
| Weight (without packaging) |
2.5 kg |
Scope of supply
| Delivery quantity in pieces |
1 |
| Components included |
all connectors required for customer interfaces |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| UL |
Yes |
| RCM |
Yes |
| EAC |
Yes |
| China RoHS |
Yes |
Usable in the following products: Detailed information can be found in the cross-list, which is available for download in the following SIOS note: 40466415
https://support.industry.siemens.com/cs/document/40466415/status-of-the-simatic-hmi-accessories-and-cross-list-update?dti=0&lc=en-WW
