SIMATIC IPC677D (Panel PC), 2x10/100/1000 Mbit/s Ethernet; 4x USB V3.0, 1x serial (COM1); Watchdog, temperature and Fan monitoring; RAID controller onboard; 22" Touch (1920x 1080); with front USB XEON E3-1268LV3 (4C/8T, 2.3 (3.3) GHz, 8 MB cache VT-D, AMT) 500 GB HDD SATA; 4 GB DDR3 1600 DIMM; 2x PCI without expansion (HW) Windows 7 Ultimate 64 bit SP1, MUI (de, en, fr, es, it) SIMATIC IPC DiagMonitor enclosed AC 110/230V industrial power supply unit with NAMUR; Power supply cable Europe
Product Type: Industrial Automation Component
General
| Article number |
6AV7260-2GA20-0BA0 |
Display
| Design of display |
22" TFT touch |
| Screen diagonal |
22 in |
Resolution (pixels)
| ● Horizontal image resolution |
1 920 pixel |
| ● Vertical image resolution |
1 080 pixel |
Backlighting
| ● MTBF backlighting (at 25 °C) |
30 000 h |
Touch operation
| ● Design as touch screen |
Yes; analog, resistive |
Installation type/mounting
| Mounting |
For horizontal and vertical mounting |
| Design |
Panel PC, built-in unit |
| central design |
Yes |
| Mounting in portrait format possible |
Yes |
Supply voltage
| Type of supply voltage |
100/240 V AC (autorange); 24 V DC |
Line frequency
| ● Rated value 50 Hz |
Yes |
| ● Rated value 60 Hz |
Yes |
Mains buffering
| ● Mains/voltage failure stored energy time |
10 ms |
Processor
| Processor type |
Celeron G1820TE (2C/2T, 2.2 GHz, 2 MB Cache); Core i3-4330TE (2C/4T, 2.4 GHz, 4 MB Cache); Xeon E3-1268L v3 (4C/8T, 2.3 (3.3) GHz, 8 MB Cache, AMT) |
| Chipset |
Intel DH82C226 PCH |
Graphic
| Graphics controller |
Intel HD graphics controller P4600 GT2 (Xeon, Core i3); Intel HD graphics controller (Celeron) |
Drives
| Optical drives |
DVD±R±RW combi-drive, optional |
| Hard disk |
3.5" SATA ≥ 500 GB, optional: 3.5" SATA ≥ 1 TB; RAID1 2x 2.5" SATA ≥ 320 GB; solid-state drive (SSD) ≥ 240 GB; all hard disk drives within the enclosure are vibration-damped; RAID1 2x 2.5" SATA ≥ 320 GB byte in removable drive bay |
| SSD |
Yes; ≥ 240 GB optional |
Storage
| Type of memory |
DDR3-1600 DIMM |
| Main memory |
2 / 4 / 8 / 16 GB; ECC optional |
| Capacity of main memory, max. |
16 Gbyte |
Data areas and their retentivity
| Retentive data area (incl. timers, counters, flags), max. |
2 Mbyte; 128 KB can be stored in the buffer time; optional |
Slots
| ● Number of PCI slots |
2 |
| ● Number of PCI slots |
2 |
Interfaces
| Number of industrial Ethernet interfaces |
2; 2x RJ45 (independent) |
| Number of PROFINET interfaces |
3; Optional |
| serial interface |
1x COM1 (RS 232), optional: 1x COM2 (RS 232) |
Video interfaces
| ● Graphics interface |
1x DisplayPort and 1x DVI-I; 1x VGA via adapter cable (optional) |
● Industrial Ethernet interface
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Interrupts/diagnostics/status information
| LED status display |
Yes |
| Bus diagnostics |
Yes |
Monitoring functions
| ● Temperature monitoring |
Yes |
| ● Fan |
Yes |
| ● Monitoring function via network |
Optional |
Degree and class of protection
| IP degree of protection |
IP20 |
| IP (at the front) |
IP65 |
| IP (rear) |
IP20 |
Standards, approvals, certificates
| CE mark |
Yes |
| UL approval |
Yes |
| ● UL 508 |
Yes |
| cULus |
Yes |
| RCM (formerly C-TICK) |
Yes |
| KC approval |
Yes |
| FCC |
Yes |
Ambient temperature during operation
Ambient temperature during storage/transportation
| ● min. |
-20 °C |
| ● max. |
60 °C |
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
tested according to DIN IEC 60068-2-6: 10 Hz to 58 Hz: 0.075 mm; 58 Hz to 500 Hz 9.8 m/s² (1 g) |
Operating systems
| pre-installed operating system |
Windows 7 Ultimate, 32-bit/64-bit, MUI; Windows Embedded Standard 7 P, 32-bit, MUI; Windows 10 Enterprise 2015 or 2016 LTSB, 64-bit, MUI |
| without operating system |
Yes |
pre-installed operating system
| ● Windows 7 |
Yes; Ultimate 32 bit or 64 bit |
| ● Windows 10 Enterprise |
Yes; Windows 10 Enterprise 2015 or 2016 LTSB, 64-bit, MUI |
Dimensions
| Width of the housing front |
560 mm |
| Height of housing front |
380 mm |
| Mounting cutout, width |
542 mm |
| Mounting cutout, height |
362 mm |
| mounting depth |
112 mm |
Weights
General Product Approval
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| Manufacturer Declaration |
Yes |
| Miscellaneous |
Yes |
| KC |
Yes |
| EAC |
Yes |
| BIS CRS |
Yes |
| China RoHS |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
Dangerous goods
| Dangerous goods information |
Yes |
| Test Summary Report UN 38.3 |
Yes |
Environment
| China RoHS |
Yes |
| last modified: |
11/24/2025 |
