SIMATIC IPC 477E 19" Touch (1366 x 768); with front USB; 4 USB (back), Ethernet (10/100/1000); Core i5-6442EQ; 3x Gbit Ethernet (IE/PN); 8 GB; without RS 232/RS485; without PCIe; Windows 10 IoT Enterprise 2016 LTSB (64-bit) for Celeron, i3 and i5; Without replaceable mass storage; 256 GB Eco SSD; Without SIMATIC software; 24 V DC industrial power supply
Product Type: Industrial Automation Component
General
| Article number |
6AV7241-5DB07-0DA0 |
General information
| Product type designation |
IPC477E |
Display
| Design of display |
19" TFT touch |
| Screen diagonal |
18.5 in |
Resolution (pixels)
| ● Horizontal image resolution |
1 366 pixel |
| ● Vertical image resolution |
768 pixel |
Backlighting
| ● MTBF backlighting (at 25 °C) |
50 000 h |
Keyboard
| ● Function keys |
No |
| ● alphanumeric keyboard |
No |
Touch operation
| ● Design as touch screen |
Yes; analog, resistive |
Installation type/mounting
| Mounting |
For horizontal and vertical mounting |
| Design |
Panel PC, built-in unit |
| central design |
Yes |
| distributed design |
No |
| Mounting in portrait format possible |
Yes |
Supply voltage
| Type of supply voltage |
100/240 V AC (autorange) 50/60 Hz; optional 24 V DC |
| Rated value (DC) |
24 V; PELV / SELV floating |
Line frequency
| ● Rated value 50 Hz |
Yes |
| ● Rated value 60 Hz |
Yes |
Mains buffering
| ● Mains/voltage failure stored energy time |
20 ms |
Processor
| Processor type |
Celeron G3902 (2C/2T, 1.6 GHz, 2 MB Cache); Core i3-6102E (2C/4T, 1.9 GHz, 3 MB Cache); Core i5-6442EQ (4C/4T, 1.9 (2.7) GHz, 6 MB Cache, iAMT); Xeon E3-1505L v5 (4C/8T, 2.0 (2.8) GHz, 8 MB Cache, iAMT) |
| Chipset |
Intel C236 / Intel H110 |
Graphic
| Graphics controller |
Intel HD graphics controller |
Drives
| Hard disk |
2.5" SATA ≥ 320 GB |
| SSD |
Yes; 128 / 240 / 480 GB |
Storage
| Type of memory |
DDR4-2400 SO-DIMM |
| Main memory |
4 / 8 / 16 GB, ECC optional |
| Capacity of main memory, max. |
16 Gbyte |
Data areas and their retentivity
| Retentive data area (incl. timers, counters, flags), max. |
512 kbyte; 128 KB can be stored in the buffer time; optional |
Slots
| ● Number of PCI slots |
1; Optional |
| ● Number of compact flash slots |
1; CFast |
Interfaces
| Number of industrial Ethernet interfaces |
3; 3x Ethernet (RJ45) |
| serial interface |
Without / 2x COM (RS 232 / 422 / 485), selectable in the BIOS |
Video interfaces
| ● Graphics interface |
2x DisplayPort |
● Industrial Ethernet interface
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Interrupts/diagnostics/status information
Monitoring functions
| ● Temperature monitoring |
Yes |
| ● Fan |
No |
| ● Monitoring function via network |
Optional |
Degree and class of protection
| IP (at the front) |
IP65 |
| IP (rear) |
IP20 |
Standards, approvals, certificates
| CE mark |
Yes |
| CSA approval |
Yes |
| UL approval |
Yes |
| ● UL 508 |
Yes |
| cULus |
Yes |
| RCM (formerly C-TICK) |
Yes |
| KC approval |
Yes |
| EAC (formerly Gost-R) |
Yes |
| FCC |
Yes |
Use in hazardous areas
| ● ATEX Zone 2 |
Yes; for inscription on device rating plate |
| ● ATEX Zone 22 |
Yes; for inscription on device rating plate |
| ● IECEx Zone 2 |
Yes; for inscription on device rating plate |
| ● IECEx Zone 22 |
Yes; for inscription on device rating plate |
| ● CCC Ex |
Yes; for inscription on device rating plate |
| ● cULus Class I Zone 1 |
No |
| ● cULus Class I Zone 2, Division 2 |
Yes; for inscription on device rating plate |
| ● cULus Class II Division 2 |
Yes; for inscription on device rating plate |
| ● FM Class I Division 2 |
No |
| ● FM Class II Division 2 |
No |
Marine approval
| ● Germanischer Lloyd (GL) |
Yes |
| ● American Bureau of Shipping (ABS) |
Yes |
| ● Bureau Veritas (BV) |
Yes |
| ● Det Norske Veritas (DNV) |
Yes |
| ● Korean Register of Shipping (KRS) |
Yes |
| ● Lloyds Register of Shipping (LRS) |
Yes |
| ● Nippon Kaiji Kyokai (Class NK) |
Yes |
Ambient temperature during operation
Ambient temperature during storage/transportation
| ● min. |
-20 °C |
| ● max. |
60 °C |
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
IEC 60068-2-6; 5 Hz to 9 Hz: 3.5 mm; 9 Hz to 500 Hz: 9.8 m/s² (with SSD or CFast); 10 Hz to 58 Hz: 0.0375 mm; 58 Hz to 200 Hz: 4.9 m/s² (hard disk) |
Operating systems
| pre-installed operating system |
Windows 7 Ultimate (Multi-Language) 64-bit, Windows Embedded Standard 7 E/P 32-bit / 64-bit, Windows 10 |
| without operating system |
Yes; Optional |
pre-installed operating system
| ● Windows 7 |
Yes; Ultimate 64 bit |
| ● Windows 10 Enterprise |
Yes; Windows 10 Enterprise 2016 LTSB, 64 bit, MUI |
Dimensions
| Width of the housing front |
483 mm |
| Height of housing front |
337 mm |
| Mounting cutout, width |
465 mm |
| Mounting cutout, height |
319 mm |
| mounting depth |
76 mm |
Weights
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
General Product Approval
| Miscellaneous |
Yes |
| UL |
Yes |
| EAC |
Yes |
| BIS CRS |
Yes |
| China RoHS |
Yes |
Maritime application
| ABS (American Bureau of Shipping) |
Yes |
| DNV (Det Norske Veritas) |
Yes |
Dangerous goods
| Test Summary Report UN 38.3 |
Yes |
| Dangerous goods information |
Yes |
| last modified: |
6/10/2026 |
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
