***No longer available*** SIMATIC IPC847C (Rack PC, 19", 4HU); Interfaces: 2 x Gbit LAN (RJ45) 1x DVI-I; audio; 2x COM; 1x LPT; 2x PS/2; 4x USB 2.0 on rear, 2x USB 2.0 on the front; Temp. and fan monitoring; Watchdog, card retainer Core I5-520E (2C/4T, 2.4 GHz, 3 MB cache, TB, VT-X, VT-D, EM64-T, AMT); Mainboard without fieldbus 2x 500 GB HDD SATA; w. removable frame; front-side 2 GB DDR3 SD-RAM (1x 2 GB), Single channel DVD-ROM; Bus module 11 slots: 7xPCI, 1x PCIE X16, 3x PCIE X4; without hardware expansions without operating system without software 110/230V industrial power supply unit with NAMUR, Power supply cable Europe
Product Type: Industrial Automation Component
General
| Article number |
6AG4114-1KM11-4XX0 |
General information
| Product type designation |
IPC847C |
Supply voltage
| Type of supply voltage |
100 - 240 V AC |
Line frequency
| ● Rated value 50 Hz |
Yes |
| ● Rated value 60 Hz |
Yes |
Processor
| Processor type |
Core i7-610E (2.53 GHz 2C/4T, 4 MB Cache, TB, VT-x, VT-d, EM64T); Core i5-520E (2.4 GHz, 2C/4T, 3 MB Cache, TB, VT-x, VT-d, EM64T); Core i3-330E (2.13 GHz, 2C/4T, 3 MB Cache, VT-x, EM64T) |
Drives
| Hard disk |
250 GB or 500 GB SATA HDD, RAID1/RAID5 HDD, 32 GB SATA SSD, installed internally on the drive carrier, in the shock and vibration-damped drive rack, or on the front drive support in the swap frame |
Storage
| Type of memory |
DDR3-SDRAM |
| Main memory |
1 GB to 8 GB, ECC optional |
| Capacity of main memory, max. |
8 Gbyte |
Interfaces
| Interfaces/bus type |
2x COM, 1x LPT, 1x DVI-I, 2x PS/2, audio (Microphone In, Line Out), 7x USB 2.0, 2x Gigabit Ethernet, PROFIBUS or PROFINET optional |
| serial interface |
COM1: 1 x V.24 (RS 232), COM2: 1 x V.24 (RS 232C) |
Video interfaces
| ● Graphics interface |
1 x DVI-I or 1 x VGA (via adapter) optional |
● Industrial Ethernet interface
| — 100 Mbps |
Yes |
| — 1000 Mbps |
Yes |
Interrupts/diagnostics/status information
| LED status display |
POWER; HARD DISK; ETHERNET 1; ETHERNET 2; PN Ι MPI/DP; WATCHDOG; TEMP; HDD1 ALARM; HDD2 ALARM; HDD3 ALARM |
Monitoring functions
| ● Temperature monitoring |
Yes |
Ambient temperature during operation
Vibrations
| ● Vibration resistance during operation acc. to IEC 60068-2-6 |
Tested according to IEC 60068-2-6: 10 cycles, 10 Hz to 58 Hz: 0.0375 mm, 58 Hz to 500 Hz: 4.9 m/s² (0.5 g) |
Operating systems
| pre-installed operating system |
Windows XP Professional, 32-bit, MUI; Windows 7 Ultimate, 32-bit, MUI; Windows Server 2008 Standard Edition incl. 5 Clients, 32-bit, MUI |
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
General Product Approval
| Manufacturer Declaration |
Yes |
| Miscellaneous |
Yes |
| KC |
Yes |
| China RoHS |
Yes |
| KC |
Yes |
| KC |
Yes |
Dangerous goods
| Dangerous goods information |
Yes |
| Dangerous goods information |
Yes |
| Test Summary Report UN 38.3 |
Yes |
Environment
| China RoHS |
Yes |
| last modified: |
6/10/2026 |
