***spare part*** SIPLUS S7-300 SM 326F based on 6ES7326-2BF01-0AB0 with conformal coating, -25…+60 °C, digital output 10 DQ; 24 V DC, 2 A, fail-safe digital output for SIMATIC S7F systems, with diagnostic alarm, 1x 40-pole
Product Type: Industrial Automation Component
General
| Article number |
6AG1326-2BF01-2AB0 |
Supply voltage
| Rated value (DC) |
24 V; 1L+ |
| Reverse polarity protection |
Yes |
Load voltage L+
| ● Rated value (DC) |
24 V; 2L+, 3L+ |
| ● Reverse polarity protection |
No |
Input current
| from supply voltage 1L+, max. |
70 mA |
| from load voltage 2L+ (without load), max. |
100 mA |
| from load voltage 3L+ (without load), max. |
100 mA |
| from backplane bus 5 V DC, max. |
100 mA |
Power loss
Digital outputs
| Number of digital outputs |
10 |
| Short-circuit protection |
Yes |
| Limitation of inductive shutdown voltage to |
L+ (-53 V) without series diode, L+ (-33 V) with series diode |
Switching capacity of the outputs
Output voltage
| ● for signal "1", min. |
L+ (-1 V) without series diode, L+ (-1.8 V) with series diode |
Output current
| ● for signal "1" rated value |
2 A |
| ● for signal "1" permissible range for 0 to 40 °C, min. |
7 mA |
| ● for signal "1" permissible range for 0 to 40 °C, max. |
2 A; 2 A for horizontal installation, 1 A for vertical installation |
| ● for signal "1" permissible range for 40 to 60 °C, min. |
7 mA |
| ● for signal "1" permissible range for 40 to 60 °C, max. |
1 A; for horizontal installation |
| ● for signal "0" residual current, max. |
0.5 mA |
Switching frequency
| ● with resistive load, max. |
10 Hz |
| ● with inductive load, max. |
2 Hz |
| ● on lamp load, max. |
10 Hz |
horizontal installation
| — up to 40 °C, max. |
7.5 A; without series diode, 5 A with series diode |
| — up to 60 °C, max. |
5 A; without series diode, 4 A with series diode |
vertical installation
| — up to 40 °C, max. |
5 A; without series diode, 4 A with series diode |
Cable length
| ● shielded, max. |
1 000 m; 200 m for SIL 3, AK 6, Cat 4 |
| ● unshielded, max. |
600 m |
Alarms
Diagnoses
| ● Diagnostic information readable |
Yes |
Diagnostics indication LED
| ● Fail-safe operation |
Yes |
| ● Group error SF (red) |
Yes |
Potential separation digital outputs
| ● between the channels |
Yes |
| ● between the channels, in groups of |
5 |
| ● between the channels and backplane bus |
Yes |
| ● between the channels and the power supply of the electronics |
Yes |
Isolation
| Isolation tested with |
500 V DC/350 V AC |
Standards, approvals, certificates
| CE mark |
Yes |
| UL approval |
Yes; File E239877 |
Highest safety class achievable in safety mode
| ● acc. to DIN VDE 0801 |
AK 5 and 6 |
| ● acc. to EN 954 |
Cat. 4 |
| ● Performance level according to ISO 13849-1 |
e |
| ● SIL acc. to IEC 61508 |
SIL 3 |
Railway application
Ambient temperature during operation
| ● min. |
-25 °C; = Tmin |
| ● max. |
60 °C; = Tmax |
Altitude during operation relating to sea level
| ● Ambient air temperature-barometric pressure-altitude |
Tmin ... Tmax at 1 080 hPa ... 795 hPa (-1 000 m ... +2 000 m) |
Relative humidity
| ● With condensation, tested in accordance with IEC 60068-2-38, max. |
100 %; RH incl. condensation/frost (no commissioning under condensation conditions) |
Use in stationary industrial systems
| — to biologically active substances according to EN 60721-3-3 |
Yes; Class 3B2 mold, fungus and dry rot spores (with the exception of fauna); Class 3B3 on request |
| — to chemically active substances according to EN 60721-3-3 |
Yes; Class 3C4 (RH < 75%) incl. salt spray according to EN 60068-2-52 (degree of severity 3). The supplied connector covers must remain on the unindustrial interfaces during operation! |
| — to mechanically active substances according to EN 60721-3-3 |
Yes; Class 3S4 incl. sand, dust. The supplied connector covers must remain on the unindustrial interfaces during operation! |
Connection method
| required front connector |
40-pin |
Dimensions
| Width |
80 mm |
| Height |
125 mm |
| Depth |
120 mm |
Weights
Classifications
| Version |
Classification |
| eClass |
16 |
| eClass |
14 |
| eClass |
12 |
| eClass |
9.1 |
| eClass |
9 |
| eClass |
8 |
| eClass |
7.1 |
| eClass |
6 |
| ETIM |
10 |
| ETIM |
9 |
| ETIM |
8 |
| ETIM |
7 |
| IDEA |
4 |
| UNSPSC |
15 |
General Product Approval
| Manufacturer Declaration |
Yes |
| China RoHS |
Yes |
| TUEV |
Yes |
| UL |
Yes |
| EAC |
Yes |
| KC |
Yes |
| RCM |
Yes |
Test Certificates
| TUEV |
Yes |
| last modified: |
3/12/2024 |
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
