Residual current operated circuit breaker, 2-pole, type A, In: 40 A, 30 mA, Un AC: 230 V
Product Type: Industrial Automation Component
General
Model
| product brand name |
SENTRON |
| product designation |
Residual current operated circuit breaker |
| design of the product |
Instantaneous |
| product type designation |
5SV3 |
General technical data
| number of poles |
2 |
| size of installation devices according to DIN 43880 |
1 |
| mechanical service life (operating cycles) typical |
10 000 |
| short-circuit current of series fuse maximum permissible |
63 A |
| short-circuit current rating |
10 kA |
| switching function short-term delayed |
No |
| degree of pollution |
2 |
| insulation voltage (Ui) rated value |
2 000 V |
| tripping fault current rated value |
30 mA |
| let-through current permissible |
5 200 A |
| I2t value permissible |
58 000 A²·s |
Supply voltage
| supply voltage for testing equipment minimum |
195 V |
| value range of the supply voltage frequency |
50 Hz |
| value range of the operating frequency |
50 Hz |
| value range of the supply voltage at AC |
230 V |
Protection class
| protection class IP |
IP20, if the distribution board is installed, with connected conductors |
switching capacity current
| ● according to IEC 61008-1 rated value |
0.5 kA |
| grid spacing |
60 mm |
power loss [W]
| ● for rated value of the current at AC in hot operating state per pole |
2.6 W |
| ● maximum |
5.2 W |
Appearance
| RAL color number |
7 035 |
| RAL color number (similar) |
7 035 |
Product details
| product feature silicon-free |
Yes |
| product extension installable supplementary devices |
Yes |
connectable conductor cross-section solid
| ● minimum |
0.75 mm² |
| ● maximum |
35 mm² |
connectable conductor cross-section stranded
| ● minimum |
0.75 mm² |
| ● maximum |
35 mm² |
tightening torque with screw-type terminals
| ● minimum |
2.5 N·m |
| ● maximum |
3 N·m |
| position of power supply cord |
top or bottom |
Mechanical Design
| height |
90 mm |
| width |
36 mm |
| depth |
70 mm |
| installation depth |
70 mm |
| number of modular width units |
2 |
| fastening method |
DIN rail |
| mounting position |
any |
| Net Weight |
188 g |
ambient temperature during operation
| ● minimum |
-25 °C |
| ● maximum |
45 °C |
| ambient temperature during storage minimum |
-40 °C |
| number of test cycles for environmental testing according to IEC 60068-2-30 |
28 |
Environment
| Environmental Confirmations |
Yes |
| Siemens EcoTech Profile (SEP) |
Yes |
| Environmental Confirmations |
Yes |
| EPD Typ II/III (with life cylce assessment) |
Yes |
General Product Approval
| CCC |
Yes |
| IMQ |
Yes |
| ÖVE |
Yes |
| VDE |
Yes |
| Miscellaneous |
Yes |
| EAC |
Yes |
| Confirmation |
Yes |
| EU declaration of conformity |
Yes |
| RCM |
Yes |
Test Certificates
other
| Chinese Quality Checkmark |
Yes |
| Confirmation |
Yes |
Railway
| Special Test Certificate |
Yes |
Dangerous goods
| Transport Information |
Yes |
Characteristic curves
https://curves.simaris.siemens.com/curves/
| last modified: |
10/9/2025 |
| Date8/1/2026 |
Subject to change without notice© Copyright Siemens 2026 |
