Modbus TCP/IP to EtherNet/IP Gateway
Gateway that creates a powerful connection between Modbus TCP/IP and EtherNet/IP networks. Provides one Ethernet port.
| Form Factor | Stand-alone DIN-rail mounted protocol gateway |
| Power Supply | 24 VDC nominal, 18 to 36 VDC allowed |
| Current Load | 500 mA max @ 24 VDC |
| Operating Temperature | -20 to 50°C (-4 to 122°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Relative Humidity | 5 to 95% (non-condensing) |
| Dimensions | 5.20H x 2.07W x 4.52D in (13.2 x 5.25 x 11.48 cm) |
| Ethernet Port | RJ45, 10Base-T half duplex, Link and Activity LEDs |
| Configuration Port | DB-9M RS-232 only, no hardware handshaking |
| Configuration Software | ProSoft Configuration Builder (PCB) |
| Serial Port Isolation | 2500V RMS per UL 1577 |
| Agency Approvals | UL/cUL Class I Div 2, ATEX, CE |
| Protocol Support | Modbus TCP/IP (Client/Server), EtherNet/IP (Client/Server) |
| Modbus Server Connections | 5 on Port 502 (MBAP), 5 on Port 2000 (Encapsulated) |
| Modbus Client | 1 client connection, up to 100 commands |
