Category: PLC systems > Power Panel > Power Panel 400 embedded
Power Panel PP420, 15" XGA color TFT display with touch screen (resistive), 1 aPCI slot, 128 MB SDRAM, 512 kB SRAM CompactFlash slot (type I), ETH 10/100, RS232, 2x USB, IP65 protection (front), 24 VDC (order screw clamp terminal block 0TB103.9 or cage clamp terminal block 0TB103.91 separately).
Technical Specifications
General information
- Battery
- Backup capacitor
- Buffer time = 10 min
- Type = Renata 950 mAh
- Service life = 3 years
- Removable = Yes, accessible from the outside
- Variant = Lithium ion
- Certifications
- CE = Yes
- UKCA = Yes
- UL = cULus E115267 Industrial control equipment
- KC = Yes
- LEDs = Power/User, CF
- B&R ID code = 0x23BF
- Power button = Yes
- Reset button = Yes
Controller
- Processor
- Type = Geode LX800
- Clock frequency = 500 MHz
- L1 cache = 128 kB (64 kB I-cache / 64 kB D-cache)
- L2 cache = 128 kB
- Expanded command set = MMX technology, 3D Now
- Floating point unit (FPU) = Yes
- Real-time clock
- Accuracy = At 25°C: Typ. 30 ppm (2.5 seconds) per day
- Battery-backed = Yes
- Power failure logic
- Controller = MTCX
- Buffer time = 10 ms
- Graphics
- Controller = Geode LX800
- Memory = 8 MB shared memory (reserved by main memory)
- SRAM
- Size = 512 kB
- Bootloader = Automation Runtime
- Flash = 2 MB (for firmware)
- Cooling = Passive via heat sink
- Mode/Node switches = 2, 16 positions each
- Watchdog = MTCX
Display
- Viewing angles
- Horizontal = Direction R / Direction L = 85°
- Vertical = Direction U / Direction D = 85°
- Backlight
- Type = LED
- Brightness = 350 cd/m²
- Half-brightness time = 70,000 h
- Filter glass
- Transmittance = -
- Anti-glare coating = -
- Touch screen
- Type = AMT
- Technology = Analog, resistive
- Controller = Elo, serial, 12-bit
- Transmittance = Up to 80% ±5%
- Type = TFT color
- Diagonal = 15" (381 mm)
- Colors = 16.2 million
- Resolution = XGA, 1024 x 768 pixels
- Contrast = 1000:1
Interfaces
- COM1
- Type = RS232, modem supported, not galvanically isolated
- Variant = 9-pin male DSUB connector
- UART = 16C550-compatible, 16-byte FIFO buffer
- Max. baud rate = 115 kbit/s
- CompactFlash slot 1
- Type = Type I
- USB
- Quantity = 2
- Type = USB 1.1, USB 2.0
- Variant = Type A
- Transfer rate = Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s)
- Current-carrying capacity = Max. 500 mA per connection
- Ethernet
- Quantity = 1
- Controller = Intel 82551ER
- Transfer rate = 10/100 Mbit/s
- Max. baud rate = 100 Mbit/s
Keys
- Function keys = No
- Soft keys = No
- System keys = No
- Service life = -
- LED luminous intensity = -
Slots
Electrical properties
- Nominal voltage = 18 to 30 VDC
- Nominal current = 1.25 A
- Bleeder resistance = 0 Ω
- Inrush current = Max. 2 A
- Power consumption = Typ. 30 W
- Galvanic isolation = Yes
Operating conditions
- Degree of protection per EN 60529 = Back: IP20 (only with connected CF card, connected aPCI module or optional aPCI cover) Front: IP65 / NEMA 250 type 4X indoor, protected against dust and hose-directed water
Ambient conditions
- Temperature
- Operation = 0 to 50°C
- Storage = -20 to 60°C
- Transport = -20 to 60°C
- Vibration
- Operation (continuous) = 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g
- Operation (occasional) = 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g
- Storage = 2 to 8 Hz: 7.5 mm amplitude / 8 to 200 Hz: 2 g / 200 to 500 Hz: 4 g
- Transport = 2 to 8 Hz: 7.5 mm amplitude / 8 to 200 Hz: 2 g / 200 to 500 Hz: 4 g
- Shock
- Operation = 15 g, 11 ms
- Storage = 30 g, 15 ms
- Transport = 30 g, 15 ms
- Elevation
- Operation = Max. 3000 m
Mechanical properties
- Housing
- Material = Metal
- Front
- Panel overlay
- Material = Polyester
- Light background color = Similar to Pantone 427CV
- Dark border color around display = Similar to Pantone 432CV
- Frame = Aluminum, naturally anodized
- Design = Gray
- Gasket = Flat gasket around display front
- Dimensions
- Width = 435 mm
- Height = 330 mm
- Depth = 86 mm
- Weight = 6700 g
