SENTRON 3WL Air Circuit Breaker, Size I, 630A, 3-Pole, Withdrawable, ETU35B
Siemens SENTRON 3WL1 Air Circuit Breaker, Size I, 630A rated current, 3-pole, withdrawable version, ETU35B electronic trip unit (LSI), 690V AC rated voltage, up to 100kA breaking capacity
| Parameter | Value |
|---|---|
| Product Brand | SENTRON |
| Product Designation | Air Circuit Breaker (ACB) |
| Series | 3WL1 (Size I) |
| Rated Current | 630 A |
| Number of Poles | 3 |
| Rated Operational Voltage | 690 / 1000 V AC |
| Rated Insulation Voltage | 1000 V |
| Rated Impulse Withstand Voltage | 12 kV |
| Breaking Capacity | 66 / 80 / 100 kA (at 500V AC) |
| Trip Unit | ETU35B (LSI) |
| Mounting Type | Withdrawable |
| Utilization Category | B |
| Operating Temperature | -25 to +70 C |
| Standard | IEC 60947-2 |
