shunt trip left 208-277 V AC 50/60 Hz 220-250 V DC accessory for: 3VA1; 3VA20-26
Product Type: Industrial Automation Component
General
| Article number |
3VA9988-0BL33 |
Model
| product brand name |
SENTRON |
| product designation |
Auxiliary release |
| accessories |
Auxiliary release |
General technical data
| degree of pollution |
3 |
| overvoltage category |
III |
| apparent power consumption / maximum |
40 VA |
| consumed active power / at DC / maximum |
35 W |
Voltage
| surge voltage resistance |
4 kV |
Mechanical Design
| height |
65 mm |
| width |
25.7 mm |
| number of slots |
3 |
| depth |
31.2 mm |
| net weight |
91 g |
| Net Weight |
82 g |
| tightening torque / with screw-type terminals / minimum |
0.4 N·m |
| tightening torque / with screw-type terminals / maximum |
0.5 N·m |
Connections according IEC
AWG number / as coded connectable conductor cross section / for auxiliary contacts
| ● minimum |
20 |
| ● maximum |
16 |
Connetctions according UL
| stripped length [in] |
0.4 in |
| tightening torque [lbf·in] / with screw-type terminals / minimum |
3.5 lbf·in |
| tightening torque [lbf·in] / with screw-type terminals / maximum |
4.4 lbf·in |
General Product Approval
| Miscellaneous |
Yes |
| EAC |
Yes |
| Confirmation |
Yes |
| EU declaration of conformity |
Yes |
| UK Declaration of Conformity |
Yes |
| RCM |
Yes |
Test Certificates
| Type Test Certificates/Test Report |
Yes |
Maritime application
other
| Miscellaneous |
Yes |
| Confirmation |
Yes |
Environment
| Environmental Confirmations |
Yes |
| Environmental Confirmations |
Yes |
| EPD Typ II/III (with life cylce assessment) |
Yes |
Tender specifications
https://www.siemens.com/specifications
Applications
This Industrial Automation Component is designed for industrial automation applications, offering reliable performance and compatibility with Siemens automation systems. Suitable for manufacturing, process control, and building automation environments.
