B&R 3UM161-6 | Industrial Automation Component

Category: To Confirm

2005 universal mixed module, 1 x 4 analog inputs ±10 V, 14-bit, 1 x 3 analog outputs ±10 V, 12-bit, 1 x 14 digital inputs 24 VDC, 1 ms, 1 digital output 24 VDC, 2 A, 500 µs, 1 digital output 24 VDC, 10 mA, 10 µs, both outputs usable as inputs, order 2x TB718 terminal blocks separately!.

Technical Specifications

Short description

• I/O module = 14 digital inputs, 2 digital outputs, 4 analog inputs, 3 analog outputs, potentiometer power supply, special functions

General information

• Diagnostics
• Power supply for digital inputs = Yes, using LED status indicator and software
• Digital outputs = Yes, using LED status indicator
• Power consumption
• 24 VDC = 4.0 W (+1.5 W for potentiometer power supply)
• 5 VDC = 2.0 W
• Total = 6.0 W
• Electrical isolation
• Channel - Channel = No
• Channel - PLC = Yes
• Potentiometer power supply - PLC = Yes
• Analog - Potentiometer power supply = No
• Digital - Analog = Yes
• Certifications
• CE = Yes
• UKCA = Yes
• UL = cULus E115267 Industrial control equipment
• Status indicators = Converter function, configuration per comparator, power supply for digital inputs, I/O function per digital channel

Potentiometer power supply

• Voltage = ±10 V
• Load = 4 x 1 kΩ parallel, total max. ±80 mA
• Short-circuit proof = Yes
• Basic accuracy = ±0.4% at 25°C

Digital inputs

• Input filter
• Hardware = ≤1 ms
• Software = -
• Quantity = 14 (+2 if the digital outputs are used as digital inputs)
• Nominal voltage = 24 VDC
• Input circuit = Sink or source
• Additional functions = Event counting, period measurement, latch input (comparator input)

Analog inputs

• Quantity = 4
• Input = ±10 V
• Input type = Differential input
• Digital converter resolution = 14-bit
• Conversion time = <45 µs for all inputs
• Output format = INT
• Input impedance in signal range = 10 MΩ
• Input protection = Protection against wiring with supply voltage
• Basic accuracy = ±0.05% at 25°C

Digital outputs

• Quantity = 2
• Nominal voltage = 24 VDC
• Nominal output current = 10 mA to 2 A
• Total nominal current = 2.01 A
• Output circuit = Source
• Output protection = Thermal shutdown in the event of overcurrent or short circuit, integrated protection for switching inductive loads, reverse polarity protection of the output power supply
• Sensor power supply = External
• Additional functions = Fast comparator output (10 µs), both outputs can also be used as digital inputs

Analog outputs

• Quantity = 3
• Output = ±10 V
• Digital converter resolution = 12-bit
• Conversion time = <45 µs for all outputs
• Switch on/off behavior = Internal enable relay for startup and errors
• Output protection = Protection against wiring with supply voltage, short-circuit proof
• Basic accuracy = ±0.05% at 25°C

Operating conditions

• Degree of protection per EN 60529 = IP20

Ambient conditions

• Temperature
• Operation = 0 to 60°C
• Storage = -25 to 70°C
• Relative humidity
• Operation = 5 to 95%

Mechanical properties

• Dimensions
• Width = System 2005 single-width
• Can be installed on
• Base unit = Yes
• Expansion unit = Yes
• Note = Order 2x TB718 terminal blocks separately
