Control Relay, 4-Pole, 2NO+2NC, DC 24V, 16A, Screw Terminals
Contactor Relay, 4 fixed contacts (2NO+2NC), DC operation DC 24V, 16A rated, screw terminals, DIN rail mount
| Parameter | Value |
|---|---|
| Product Designation | Contactor Relay / Control Relay |
| Series | 3TH30 |
| Contact Configuration | 2 NO + 2 NC |
| Number of Poles | 4 |
| Control Voltage | 24 V DC |
| Rated Insulation Voltage | 690 V |
| Rated Impulse Withstand Voltage | 8 kV |
| Rated Operating Current (AC-12) | 16 A |
| Rated Operating Current (AC-15 at 240V) | 10 A |
| Protection Class IP | 20 |
| Mechanical Endurance | 30 million cycles |
| Operating Temperature | -25 ... +55 °C |
| Terminal Type | Screw terminal |
| Mounting | DIN rail / screw mounting |
