B&R 3PS465-9 | Industrial Automation Component

Category: To Confirm

2005 power supply module, 24 VDC, 50 W, with expansion slot.

Technical Specifications

Short description

• Power supply module = 24 VDC with expansion slot

General information

• Output power
• 24 VDC = 50.0 W
• 5 VDC = 40.0 W
• Total = 60.0 W
• Electrical isolation
• Power supply unit - Input voltage = Yes
• Certifications
• CE = Yes
• UKCA = Yes
• UL = cULus E115267 Industrial control equipment
• Status indicators = Input voltage OK, output voltage OK

Power supply unit

• Input voltage range = 18 to 30 VDC
• Input current = Max. 3.5 A
• Overload characteristics = Short-circuit-proof, overload-proof, reverse polarity protection
• Contact for READY relay = Yes, designed as normally open contact
• Fuse = 6.3 A slow-blow / 250 V
• Additional functions = External retention of RAM by supplying 12 V (min. 8 V / max. 30 V)

Operating conditions

• Degree of protection per EN 60529 = IP20

Ambient conditions

• Temperature
• Operation = 0 to 60°C
• Storage = -25 to 70°C
• Relative humidity
• Operation = 5 to 95%

Mechanical properties

• Dimensions
• Width = System 2005 double-width
• Slot
• Base unit = 1 + 2
• Expansion unit = 1 + 2
