B&R 3DM486-6 | Industrial Automation Component

SKU: 3DM486-6
(5)
$1,082.58
-52% $2,245.24 $1,082.58
In stock
Usually ships within 24 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 18017464056

Category: To Confirm

2005 digital mixed module, 16 inputs 24 VDC, 1 ms, sink/source, 16 transistor outputs 24 VDC, 0.5 A, input and output group, electrically isolated, order 2x terminal blocks TB718 separately!.

Technical Specifications

Short description

  • I/O module = 16 digital inputs, 16 digital outputs

General information

  • Diagnostics
  • Outputs = Yes, using LED status indicator and software
  • Output monitoring = Yes, using LED status indicator and software
  • I/O power supply = Yes, using LED status indicator and software
  • Power consumption
  • Internal
  • 24 VDC = -
  • 5 VDC = 1.2 W
  • Total = 1.2 W
  • External 24 V (DO) = 2.2 W
  • Electrical isolation
  • Group isolation = Input group - Output group
  • Channel - Channel = No
  • Channel - PLC = Yes
  • Certifications
  • CE = Yes
  • UKCA = Yes
  • UL = cULus E115267 Industrial control equipment
  • Status indicators = I/O function per channel, I/O power supply for inputs and outputs, output monitoring

Digital inputs

  • Input filter
  • Hardware = ≤1 ms
  • Software = -
  • Nominal voltage = 24 VDC
  • Input circuit = Sink or source

Digital outputs

  • Nominal voltage = 24 VDC
  • Nominal output current = 0.5 A
  • Total nominal current = 8.0 A
  • Output circuit = Source
  • Output protection = Thermal shutdown in the event of overcurrent or short circuit, integrated protection for switching inductive loads, reverse polarity protection of the output power supply
  • Sensor power supply = External

Operating conditions

  • Degree of protection per EN 60529 = IP20

Ambient conditions

  • Temperature
  • Operation = 0 to 60°C
  • Storage = -25 to 70°C
  • Relative humidity
  • Operation = 5 to 95%

Mechanical properties

  • Dimensions
  • Width = System 2005 single-width
  • Can be installed on
  • Base unit = Yes
  • Expansion unit = Yes
  • Note = Order 2x TB718 terminal blocks separately
