B&R 3CP360-60-1 | Industrial Automation Component

SKU: 3CP360-60-1
(1)
$5,816.03
In stock
Usually ships within 24 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 18017464056

Category: To Confirm

2005 CPU, Pentium 266, 32 MB DRAM, 512 kB SRAM, removable application memory: CompactFlash, 1 insert slot for aPCI modules, 1 USB interface, 1 RS232 interface, 1 Ethernet interface 100BASE-T, order application memory separately!.

Technical Specifications

Short description

  • Interfaces = 1x RS232, 1x Ethernet, 1x USB
  • System module = CPU
  • CPU = Pentium 266

General information

  • Diagnostics
  • Battery = Yes, using LED status indicator and software
  • CPU function = Yes, using LED status indicator
  • CompactFlash = Yes, using LED status indicator
  • Ethernet = Yes, using LED status indicator
  • Support
  • ACOPOS support = Yes
  • Visual Components support = Yes
  • Power consumption
  • 24 VDC = 3.0 W
  • 5 VDC = 11.0 W
  • Total = 14.0 W without memory card and without interface module
  • Electrical isolation
  • IF1 - IF2 = Yes
  • IF1 - IF3 = No
  • IF2 - IF3 = Yes
  • PLC - IF1 = No
  • PLC - IF2 = Yes
  • PLC - IF3 = No
  • Certifications
  • CE = Yes
  • UKCA = Yes
  • UL = cULus E115267 Industrial control equipment
  • Status indicators = CPU function, battery, CompactFlash, Ethernet

Controller

  • Processor
  • L2 cache = 512 kB
  • Data buffering
  • Battery monitoring = Yes
  • Lithium battery = At least 3 years
  • Standard memory
  • RAM = 32 MB DRAM
  • User RAM = 496 kB SRAM
  • CompactFlash slot = 1
  • L1 cache for data and program code = 2x 16 kB
  • Real-time clock = Nonvolatile, resolution 1 s
  • Insert slots = 1 for IF7xx aPCI interface modules
  • Floating point unit (FPU) = Yes
  • Integrated I/O processor = Processes I/O data points in the background
  • Reset button = Yes
  • Remanent variables = 256 kB
  • Shortest task class cycle time = 400 µs
  • Typical instruction cycle time = 0.02 µs

Interfaces

  • Interface IF1
  • Type = RS232
  • Execution = 9-pin male DSUB connector
  • Max. transfer rate = 115.2 kbit/s
  • Interface IF2
  • Type = Ethernet
  • Execution = Shielded RJ45 port
  • Line length = Max. 100 m between two stations (segment length)
  • Transfer rate = 10/100 Mbit/s
  • Interface IF3
  • Type = USB 1.1
  • Quantity = 1
  • Execution = Type A

Operating conditions

  • Degree of protection per EN 60529 = IP20

Ambient conditions

  • Temperature
  • Operation = 0 to 60°C
  • Storage = -25 to 60°C
  • Relative humidity
  • Operation = 5 to 95%

Mechanical properties

  • Dimensions
  • Width = System 2005 double-width
  • Slot
  • Base unit = 3 + 4
  • Expansion unit = No
  • Note = Order application memory (CompactFlash) separately, backup battery included in delivery
